Military

Analytic Systems has designed high performance power conversion solutions for a variety of Military applications. We've supplied the US, Canada, NATO, Foreign Military as well as state and local emergency agencies. Analytic Systems has supplied DC-DC Voltage Converters, DC-AC Inverters, AC-DC Power Supplies, as well as all types of battery chargers to almost every branch of the US Military. In addition to the MBU Power Supply for the US Army field kitchens, the US Military uses customized versions of the PWS1510, PWS310, VTC615-24-24 and BCA1510 in various operations.

Most of the products that we manufacture are C.O.T.S. (Commercial Off The Shelf) and can be modified for military use. Our Military products are built to meet or exceed MIL-STD810D, Method 514-3 and Cat-I Procs C.O.T.S., MIL-PRF 44485 and EMC radiated and conducted emissions MIL-STD 461E. All C.O.T.S. products are manufactured in accordance with IPC-A-610 and many can be built to IP66 or IP67 requirements.

We have the manufacturing capacity, engineering expertise, technical sales experience and a comprehensive product offering to ensure that rugged, reliable, high performance power conversion products are able to meet your military power system needs. We believe in and implement the Functionality, Usability, Reliability, Performance and Supportability Model for our military specific products

Analytic Systems' PWS1510MS-28PK Power Supply is integrated into the US Army's C-RAM System. View this video to see the PWS1510MS-28PK in application and read more about this project here.



Transit & Rail

Serving the power needs of the rail transportation industry means building products for the most unforgiving environments for electronics of any kind. These are the electronics you use to keep your equipment running, and that’s important. The combination of heat, dirt, moisture, metallic and corrosive dust can rapidly deteriorate electronics that are not up to the task. To power your equipment, use Analytic Systems as your Ruggedized Power Problem Solution.

The keys to a successful electronics installation on a locomotive are placement and ruggedization. Analytic Systems can supply the products you can trust to perform. With wide temperature components, dust / moisture / vapor ruggedization and vibration proofing, an Analytic Systems unit will stay on the job. Download our Commuter Rail brochure for more information.

Last year, we developed the BCA-PWS-480-36 Power System for Illinois Commuter Rail Operator Metra, who was experiencing unacceptable downtime with their low voltage power supply (powering all low voltage electrical on board). Analytic Systems designed and manufactured 480V 3 phase input UPS combining both an AC to DC power supply and a separate battery charger that provides regulated 32VDC power to the voltage power systems. In case of a failure, the low voltage systems are maintained from the batteries. To learn more about this project, and how we can prepare a customized unit for your needs, check out the Metra white paper and visit our OEM/Customization page.

Heavy Equipment

The operation of a motor control device, commonly used on forklifts, front end loaders, small utility vehicles utilizing thyristors, can cause a negative spike to be generated. Any electronics sharing a common power system can be affected by these negative spikes. Analytic Systems has developed a modification to prevent these negative spikes from accidentally shutting down its power conversion units.

We are often called upon to supply fully isolated DC-DC converters to produce 15 - 16 volts DC, at 5 to 7 amps from forklifts, 36 or 48 volts DC to run notebook computers. These are particularly tough applications as the thyristor-based motor drives for the forks and tires produce large amounts of overlying AC on the batteries and will cause many converters to fail unless proper input-circuitry is used. We call this the ‘Forklift’ Modification. If your application is for any system where such motor drives are used on the source voltage side, let us know so we can make the proper modifications.

Industrial

Industrial-quality construction of our products with optional enhanced ruggedization features ensures that they function optimally in the harshest environments.

All of our products have very low EMC, and are uniquely robust using expensive heavy gauge copper conductors. Every standard product we manufacture is accompanied with a 3 Year Warranty.

Many of the products manufactured by Analytic Systems are used in Utility and Heavy Industrial environments. Common Utility voltage is 110 volts DC, however, power is required at 24 VDC for SCADA or PLC applications. We produce a series of fully isolated DC-DC voltage converters that convert 110 VDC (90-140 VDC Actual) to a fully regulated 27.2 VDC at 300, 600, 1000 and 1500 watts. When provided with the optional paralleling diodes, multiple units can be run in parallel for additional power or redundancy. If the application calls for batteries at the 24 VDC level, we also manufacture DC-DC battery chargers at 300, 600, 1000 and 1500 watts.

Marine [Commercial]

Analytic Systems has over 30 years experience in providing power conversion solutions to the most challenging marine environments. Our products have been used in numerous applications including in tug boats, work boats, commercial fisheries, military and coastguard applications, oil platforms, shipyards, ferries and even oceanographic vessels.

Analytic Systems has supplied DC-DC Voltage Converters, DC-AC Inverters, AC-DC Power Supplies, as well as all types of battery chargers to almost every branch of the US Navy . The US Navy uses the VTC615-24-24 Voltage Converter. NAVAIR uses the IPS600-12-110 and IPS1000-20-110 Pure Sinewave Inverters, the USMC uses the VTC 305 Voltage Converter and the Canadian Coast Guard uses the VTC615 to supply clean power to their gyroscopes.

Our products feature a standard marine ruggedization profile from the chassis to the components. Using industry proven technology and innovative engineering, Analytic Systems provides the efficient, reliable chargers and power products the commercial mariner needs.

Marine [Recreational]

Having provided a wide variety of successfully proven power conversion products in the recreational marine market, we are confident that our products will provide the reliability and flexibility necessary.

We have a wide variety of battery charging solutions to the recreational marine market. Passagemakers will appreciate the reliability and ruggedness of our flexible BCA series of chargers. These chargers provide a true three stage charging algorithm to safely and quickly charge any variety of lead-acid battery and they have a timed, manual start equalization cycle for routine battery maintenance and longer battery life. Our value priced SEC family of three stage 12v and 24v battery chargers are the perfect fit for the boater looking for a full featured, inexpensive charger. Available with volt/amp meters in 15, 25,30,and 45A.

Telecommunications

Analytic Systems provides power conversion products for a variety of telecommunications applications. Having provided customized AC/DC Battery Chargers, DC/DC Voltage Converters (for use on postive or negative ground systems) and DC/AC Inverters to the most demanding organizations such as NASA, Lockheed Martin, BAE, Telephonics.

Battery Chargers are available for 12, 24 or 48-VDC battery systems. Power levels are 300, 600 or 1000 watts. Source voltages include 110 or 220 VAC, 12, 24, 48, 110 or 250 VDC. Charging profiles are selectable between 2 and 3-stage, and include manually initiated equalize. Temperature compensation is standard. The 300-watt models (BCA310 & BCD310) are wall-mountable. The 600 and 1000-watt models (BCA610, BCA1000, BCD610 & BCD1000) are available as wallmount or rackmount units.

A wide range of DC-DC Voltage Converters are available. Common negative step-down models range from 60 to 600 watts. Common negative step-up models range from 120 to 600 watts. Fully-isolated models are available in 5 and 7 amps (VTC120i & VTC120ih Series), as well as 600 and 1000 watts (VTC610, 615, 1000 and 1015 Series) are also available in rackmount and come standard with digital volt and amp displays.

Power Supplies from 110 or 220 VAC are available in 120, 240, 300, 600 and 1000 watts. The 120, 240 and 300-watt models are available in wallmount only. Digital Voltage and Current Displays are optional for the 300, 600 and 1000-watt models. The 600 and 1000-watt models are available in wall or rackmount and include the digital displays as standard.

Analytic Systems' Inverters have a multi-stage filter on the input and output, and have large hold-up capacitors on the internal 200 VDC or 400 VDC rail for complete elimination of the 60 Hz ripple on the inverter input. In addition to quality of workmanship, this concept indicates that our inverters comply fully with EMI requirements for EN 55022 Class B with a significant dB margin. The audio frequency range noise (C-message) on the input is also very low.

Alternative Energy

We have focused our extensive R&D program on solar power. Specifically designed for use with a wide range of photovoltaic cells, the new SolarMax, 100Amp MPPT Solar Charge Controller is suitable for many different applications. Using alternative sources of energy involves some form of energy storage and conversion. We provide products that use the output from any of these sources to change batteries (DC to AC source battery chargers), as well as products to convert the output of the batteries to the required power at the load, including both DC-DC Converters and DC-AC Inverters. Designed for the rugged demands of heavy-duty industrial markets, our reliable and robust products will provide years of trouble free service for alternative energy users and manufacturers.

Analytic Systems will take on custom design projects. An example of one such project is our Ni-Cad Solar Battery Charger. Custom-built for Canadian National Railways (CNR), it converts the output from a 6 or 12-volt, nominal solar panel to 1.5 or 3.0 VDC to charge high-capacity Ni-Cad batteries, at up to 15 amps, and meets the stringent requirements for mounting directly adjacent to railway tracks in any ambient temperature

Transport

Few industries can be more punishing to equipment than commercial trucking and yet Analytic Systems' products excel at providing reliable, clean power while integrating innovative transportation systems that lower operating costs.

Analytic Systems' products are used as power supplies for communications, lighting, asset tracking, high efficiency inverters for cab conveniences and charge controllers for battery based AC units or motor loads in ANTI-IDLE systems. Like the customers they serve our products have been proven reliable by a life on the road.

Oil & Gas

For over 30 years Analytic Systems has designed high performance power conversion products to meet the standards for reliability needed for use in rugged and harsh environments such as oil & gas. Our product's modern designs use efficient filtering, the circuit boards are uniquely robust using expensive heavy gauge copper conductors; designed by Analytic Systems’ engineers and assembled in our Canadian factory. Four ruggedization options also available:

• Simple moisture protection
• Water resistance
• High vibration
• Wide temperature operation

Models are available to step-up, step-down, stabilize or isolate AC or DC power over a range of 12 to 360 Volts, and all standards products we manufacture are backed with a three-year warranty. A number of our Class 1, Div 2, 24 to 12-volt Voltage Converters are used throughout the Oil & Gas Industry for Off-Grid SCADA applications. We can modify most of our 300&600 Watt power conversion products to meet a specific need.

Rail Track

Serving the power needs of the rail transportation industry means building products for the most unforgiving environments for electronics of any kind. These are the electronics you use to keep your equipment running, and that’s important. The combination of heat, dirt, moisture, metallic and corrosive dust can rapidly deteriorate electronics that are not up to the task. To power your equipment, use Analytic Systems as your Ruggedized Power Problem Solution.

The keys to a successful electronics installation on a locomotive are placement and ruggedization. Analytic Systems can supply the products you can trust to perform. With wide temperature components, dust / moisture / vapor ruggedization and vibration proofing, an Analytic Systems unit will stay on the job.

Steel Mills

Steel mill electronics operate in one of the most unforgiving environments for electronics of any kind. The combination of heat, dirt, metallic and corrosive dust can rapidly deteriorate electronics that are not up to the task.

Our DC-DC Voltage Converters are also widely used in industrial applications, ranging from steel mills to factory and distribution warehouses. Again, voltage converters that convert 110 or 250 VDC or other required voltages from 12 to 24 volts DC for control or communications are common applications. Steel mills, and other heavy industry applications are difficult because the source voltage is very dirty, with many spikes and voltage reversal on the input side. Over years of practical experience, we have developed converters that are capable of surviving and providing years of reliable service, even in such rough environments.
